1 14184046 1 动力系统 POWER SYSTEM
2 14185464 1 平台管路 Platform piping
3 14178283 1 回转平台 Revolving Frame
4 A820606030364 1 密封垫 Gasket
5 A820101117871 1 盖 Cover
6 A210111000101 2 螺栓M12×25GB5783 10.9级 Bolt
7 24000639 2 垫圈12GB97.1 达克锈 Washer
8 14185250 1 覆盖件总成 Assembly panels
9 13444417 1 空调系统 Air conditioning
10 变更或见其他配置 1 配重总成 Counterweight assembly
11 13587578 1 回转支承总成 Rotary bearing assy
12 14013222 1 驾驶室 cab
13 14185331 1 先导管路 Pilot Pipeline
14 12487116 1 橡胶护套 Rubber protective sleeve
15 13345424 4 套 bush
16 A229900010252 4 螺栓M36×3×320GB5785 10.9级 bolt
17 11844004 1 橡胶护套 Rubber protective sleeve
18 12486982 2 橡胶护套 Rubber protective sleeve

1 60238141 1 发动机 engine
2 13443490 1 排气系统 Exhaust system
3 13434409 1 减震传动系统 Damping and transmission system
4 13443476 1 燃油系统 fuel system
5 13441476 1 冷却系统 cooling system
6 14184035 1 进气系统 air inlet system

1 60311904 1 发动机修理包 Engine maintenance package
2 60311905 1 垫圈修理包 Washer repair set
3 60311906 1 气门室盖总成 Air valve chamber cover assembly
4 60311911 1 缸盖总成 Cylinder cover assembly
5 60311929 1 机体总成 Air cylinder body assembly
6 60311942 1 油底壳总成 Oil pan assembly
7 60311946 1 凸轮轴和气门总成 Camshaft and valve assembly
8 60311965 1 曲轴活塞总成 Crankshaft and piston assembly
9 60311977 1 齿轮室总成 Timing gear case assembly
10 60311988 1 进气总成 Air intake assembly
11 60311161 1 排气总成 Exhaust assembly
12 60311167 1 下排气系统 Ventilation system
13 60311176 1 水泵总成 Water pump assembly
14 60311189 1 节温器总成 Thermostat assembly
15 60311200 1 发动机水管 Engine water piping
16 60311211 1 风扇皮带总成 Fan and belt assembly
17 60311217 1 增压器系统 Turbocharger system
18 60311226 1 燃油喷射系统 Fuel injection system
19 60311838 1 过滤系统 Filter system
20 60311840 1 燃油进出油管系统 Fuel pipe system

60311845 1 机油冷却系统 Oil cooler system
60311850 1 机油泵总成 Engine Oil Pump assembly
60311855 1 机油管路 Engine oil piping
60311862 1 EGR总成 EGR assembly
60311882 1 电气元件 Engine electrical control parts
60311895 1 冷却系统 Radiator system
60311897 1 燃油电子泵 Fuel tank

60311907 1 气门室盖总成 Air valve chamber cover assembly
B229900005123 1 机油盖 Cap AS, Engine Oil Filler
B229900005124 1 机油盖垫 Cover pad of engine oil
60093241 4 螺栓028050-8450 M8×45凸缘 Bolt
B229900004857 11 螺栓 M8×70凸缘 Bolt 028050-8700 M8×70 flange
B229900004434 11 橡胶 Rubber
60311908 2 双头螺柱 Stud 894386-5120 M8×28 L=38
B229900004560 1 垫片 Spacer
60311909 1 垫片 Gasket
B229900004192 1 板 Plate
B229900004849 8 螺栓 M8×12凸缘 Bolt 028050-8120 M8×12 flange
B229900004785 6 螺钉 Screw
60311910 1 气门室盖下部总成 Air valve chamber lower cover

60311912 1 缸盖总成 Cylinder cover assembly
60311913 1 缸盖垫 Cylinder Cushion
60311914 26 螺栓898260-0050 M14×115 凸缘 Bolt 898260-0050 M14×115
60311915 24 气门导管 Valve Conduit
60311916 12 进气门座 Inlet-valve seat
60311917 12 排气门座 Exhaust valve board
B229900004227 1 堵盖 Blanking cover
B229900004651 7 堵塞 Plug, Cup
B229900004652 6 堵塞 Plug
B229900004655 7 堵塞 Plug
B229900004662 11 堵塞 Plug
60311918 6 预热塞 Preheater Plug
60311919 1 预热塞连片 Connecting Disc of Preheater Plug
60311920 1 预热塞连片 Connecting Disc of Preheater Plug
B229900005013 12 螺柱 Threaded stud
B229900004802 8 螺母 Nut 091180-2080 M8 flange
60311922 12 导向杆 Guide rod
60008998 2 螺栓 Bolt
B229900005029 6 喷油嘴垫片 Washer
B229900004854 2 螺栓 Bolt 028050-8350 M8×35 flange

60009002 2 螺柱 thread pole
60311939 1 堵塞 Plug
60008996 1 堵塞 plug
60311923 1 支架 Bracket
60009000 1 螺栓 bolt
60009001 1 螺栓 bolt
60311924 1 惰齿轮 Idler gear
B229900004231 1 惰轮轴 Idler wheel axle
60311925 2 插销 Inserted pin
60311926 1 线夹 Clip
60311927 1 吊耳 Shackle
B229900004398 1 前吊耳 Front shackle
B229900004816 6 螺母 M4凸缘 Nut 897368-8530 M4 flange
B229900004538 6 垫片 Spacer
60311928 6 喷油嘴 Fuel Injector Nozzle

60311930 1 气缸体总成 Air cylinder body assembly
60311931 6 四配套187813-7661 1级 Air cylinder bush component first-
60311932 6 四配套187813-7671 3级 Air cylinder bush component third-
B229900003271 6 气缸套1级 Air cylinder bush 1-class
B229900003272 6 气缸套3级 Air cylinder bush 3-class
B229900004722 1 过渡接头 Transitional Joint
B229900005059 2 销 shaft
B220401001134 1 阀 valve
B229900004547 1 垫片 Spacer
B229900004650 4 堵塞 Plug
B229900004652 1 堵塞 Plug
B229900004657 1 堵塞 Plug
B229900004659 4 堵塞 Plug
B229900005061 4 销 shaft
B229900004661 1 堵塞 Plug
60311933 6 #冷却喷头 Cooling sprayer
60311934 1 堵塞 Plug
B229900004662 3 堵塞 Plug
B220401001135 6 阀 Valve
60311935 2 衬套 Bush

21 B220400000444 1 放水阀 Valve
22 B229900004405 1 软管 HOSE
23 B229900004951 25 螺栓 Bolt
24 60311936 14 螺栓897077-6380 M14×115 凸缘 Bolt 897077-6380 M14×115
25 B229900005062 2 销 shaft
26 B229900005009 1 螺柱 Stud
27 B229900004536 1 垫片 Shim
28 B229900004521 1 垫片 Shim
29 60311937 1 堵塞 Plug
30 B229900004754 1 卡箍 Clip
31 60311938 1 堵塞 Plug
32 60311939 4 堵塞 Plug
33 60008996 1 堵塞 plug
34 B229900004422 2 套 Sleeve
35 B229900004226 1 定向杆 Directional rod
36 B229900005002 2 螺柱 Threaded stud
37 B229900004802 2 螺母 Nut 091180-2080 M8 flange
38 B229900004658 1 堵塞 Plug
40 60311940 2 双头螺柱 Stud 894386-5120 M10×46.5
41 60311941 1 堵塞 Adapter

60311943 1 油底壳 Oil pan
60311944 1 油标尺 Oil scale
B229900004520 1 垫片 Gasket
B229900003258 1 放油螺塞 Plug
B229900004489 1 标尺导管 Measuring scale conduit
60311945 2 片 Gasket
B229900004850 1 螺栓 Bolt 028050-8160 M8×16 flange
B229900004871 30 螺栓 Bolt 028080-8180 M8×18 flange
B229900004799 4 螺母 Nut 091180-1080 M8 flange
