SANY Frame Assembly – Parts Catalog (ODT010093271)

Part Number: ODT010093271
Machine Model: SKT95H Mining Wide-Body Dump Truck
Equipment No.: ODT100000249
Catalog Section: Chapter 10

ODT010093271 Frame组件
ODT009852342 钢管Bracket
A210405000011 Washer
A210111000018 Bolt
21001328 Washer
ODT009171915 Front连接板
21001338 Washer
A210491000132 Washer
A210111000043 Bolt
ODT009171929 Rear连接板
A210110000281 Bolt
60023433 Washer
A210111000222 Bolt
A210110000058 Bolt
A210111000055 Bolt
ODT005199507 连接座
ODT005199510 调整Gasket
A210307000035 Nut
ODT004701624 连接板
A210110000360 Bolt
14352951 圆管
ODT008280083 安装板
A210501000013 销
14420950 圆管安装座
21017191 Bolt
A210491000144 Washer
A210307000017 Nut
A210307000028 Nut
ODT005255217 摄像头Bracket
A210111000089 Bolt
A210111000243 Bolt
14494513 拖钩销
ODT006274719 调整Gasket
ODT006274694 调整Gasket
A210111000030 Bolt
131402010257A058 垫圈……………………………….. 3-9 131402010257A059 Steering横拉杆Assembly………………… 3-9
160102140001A185 O形圈…………………………… 5-15 160102140001A186 定位套………………………….. 5-15
A210314000007 螺母………………………………….. 3-35 A210314000009 Nut………………………………….. 6-53
ODT009113872 横梁………………………………….. 4-17 ODT009113881 Engine Hood支撑梁……………………… 4-3
