SY155C Group 18 14361212 Electrical System
Model: SY155C2I5KU Hydraulic Excavator
Part Number: N/A
Contact: salesany@yeah.net
Parts List
| Part No. | Description |
|---|---|
| 140704000284A | Control Display |
| 14043981 | Camera Guard |
| SSY005227872 | Front Cover Plate Assembly |
| A249900000964 | Camera |
| 60066402 | Acid Battery |
| 141699000005C | Light, Beacon |
| B240200000059 | Emergency Stop Button |
| 60050766 | Contact Module |
| 13168021 | Bracket |
| 61022402 | Knob Switch |
| 12060843 | Wire Clip Mitsubishi |
| 12060897 | Sumitomo Connector Fixed Clamp |
| 12061200 | Wire Clip of Swp |
| 12061491 | Clip |
| 60013321 | A-battery Negative Wire |
| 60013322 | A-accumulator Positive Wire |
| 14502660 | Power Line |
| 60012791 | Power Supply Harness |
| 60018110 | Power Supply Harness |
| 60209655 | Power Supply Line |
| 60193107 | Cable, Battery |
| 60060548 | Washer |
| 60083322 | Cord Clamp |
| 60086353 | Wire Clip |
| 60086355 | Wire Clip |
| 60086357 | Wire Clip |
| A210111000012 | Bolt |
| A210111000101 | Bolt |
| A239900000053 | Nylon Ties |
| 60197034 | Cluster Fixed Lace |
| 60202078 | Cluster Fixed Lace |
| 60358300 | Tape |
| 141604000064C | Light |
| 60208141 | Wire Clip |
| 60149606 | Wire Clip |
| 60119587 | Wire Clip |
| 14361212 Electrical System | (1/2) |
| B240700000250 | Relay |
| 140601010175B | Sany Control Unit |
| 13439765 | ECM Fixed Plate |
| 61030659 | Radio |
| 61001773 | Epad08 |
| 61001774 | Epad08 |
| 60211508 | Throttle Knob |
| 142507000021E | Switch, Key |
| 60241902 | Horn |
| 13989617 | Driver’s Cab Harness |
| 13989618 | Vehicle Body Harness |
| 14484300 | GPS Harness |
| 60060562 | Washer |
| 24000630 | Washer |
| 24000632 | Washer |
| 11400099 | Wire Clip of Amp |
| 24000633 | Washer |
| 60060546 | Washer |
| 60086354 | Wire Clip |
| 60086356 | Wire Clip |
| A210210000030 | Screw |
| A210210000002 | Screw |
| A210204000220 | Screw |
| A210111000343 | Bolt |
| 24002251 | Screw |
| 140103020024B | DC/DC Converter |
| 142301000082B | Fuse Box |
