1 60003500 2 管夹 Clamp
2 60003647 1 燃油管 Tube, fuel

1 60003483 1 惰轮 Gear, idler
2 60003484 1 惰轮支架 Bracket, idler gear
3 B229900004850 2 螺栓 Bolt

1 60269356 1 空气预滤器 pre-separation
2 10386841 1 预滤钢管法兰 Bracket, precleaner
3 A210111000343 6 螺栓M8×20GB5783 10.9级 Bolt
4 24000633 7 垫圈8GB97.1 达克锈 Washer
5 13073423 1 预滤进气胶管 air intake rubber
6 13073275 1 空滤支架 air filtering bracke
7 10083933 1 空滤卡箍 Hoop, air cleaner
8 A210111000092 1 螺栓 Bolt
9 60218893 1 空气滤清器 Air cleaner
10 A229900003759 3 T型抱箍 Clamp
11 13073422 1 进气连接胶管 air intake rubber
12 A229900002031 3 T型抱箍 Clamp
13 13423755 1 进气管 air intake tube SY55C9I3R.1.3A.4-
14 60148482 1 空滤传感器 Sensor, air cleaner
15 A210491000120 4 垫圈 Washer Flat M10
16 B229900003909 1 空滤传感器接头 Connector, sensor,air filter
17 13196707 1 空滤安装板 mounting plate for air
18 A210111000012 4 螺栓 M10×20GB5783 10.9级 Bolt
19 21004569 1 T型抱箍 Clamp

1 60180748 1 堵头 Plug
2 60229053 1 壳体组件 CASE ASSEMBLY
3 B222100000591 1 空气滤清器安全滤芯 Filter core, air filter,safety
4 B222100000593 1 空气滤清器主滤芯 Filter core, air filter,main
5 60078237 1 端盖组件 Cover, end,GP
6 60078235 1 排尘阀 Valve,dust,exhaust

1 A210307000055 2 螺母M8GB6170 10级 Nut M8GB6170 10
2 24000633 2 垫圈8GB97.1 达克锈 Washer
3 60205702 1 消声器总成 Muffler GP
4 10685355 2 管带 Clip
5 变更或见其他配置 4 螺栓 Bolt
6 A210491000120 4 垫圈 Washer Flat M10
7 12799806 1 消音器支架 Supporting, silencer
8 B229900002784 1 排气管垫圈 Gasket
9 12765007 1 排沙管支架 Bracket, Pipe
10 A229900001347 1 软管环箍 Clamp, Hose
11 12799646 1 消音器引水胶管 Muffler Water Plastic
12 A210204000334 1 螺钉M10×16GB70.1 10.9级 Screw

1 A210491000120 13 垫圈 Washer Flat M10
2 11728244 1 软轴固定板 Plate, fixing, flexible bearing
3 13437972 1 软轴固定架 fixed frame SY55C9I3R.1.3A.5.1
4 60176191 2 线束固定夹 the fixty of line
5 A210111000343 3 螺栓M8×20GB5783 10.9级 Bolt
6 A210204000347 2 螺钉M8×35GB70.1 10.9级 Bolt M8x35 Cap Screw
7 60225886 1 螺钉M8×70GB70.1 10.9级 Bolt M8x70 Cap Screw
8 12435332 1 预滤进油管 Oil inlet tube of primary
9 21053360 10 软管环箍 Hose ring hoop
10 13495511 1 燃油箱总成 Fuel Tank Assy
11 11144769 1 海绵 Seal
12 12435228 1 发动机进油管 oil inlet tube of engine
13 12435715 1 回油管 Tube, return
14 A210111000202 4 螺栓 Bolt
15 60060548 4 垫圈12GB96.1 达克锈 Washer 12GB96.1
16 13303621 1 粗滤放水管 filter drainage tube
17 A820606020543 1 软管 Hose
18 60018586 2 燃油管总成 Hose GP, fuel
19 60064766 2 铰接螺栓 Link bolt
20 60064764 4 垫片 Shim

21 60064763 1 燃油粗滤器 Fuel coarse filter
22 A210111000024 3 螺栓 Bolt
23 24000512 6 垫圈10GB93 达克锈 Washer
24 A210204000357 3 螺钉M10×60GB70.1 10.9级 Screw
25 60099069 1 电机TB0.25-24-1.5步进角1.8度 Motor,throttle
26 A210204000220 1 螺钉M8×20GB70.1 10.9级 Screw M8×20GB70.1 10.9
27 11626828 1 油门电机拐臂 Arm, throttle motor
28 12799912 1 马达支架 motor supportSY60C1I2R.1.3.5.4A
29 60208479 1 推拉软轴 throttle guy assembly
30 60142857 1 熄火软轴 Manual flameout control cable
31 A210204000334 4 螺钉M10×16GB70.1 10.9级 Screw
32 12063165 1 固定架 fixed frame
33 60122059 3 螺栓M10×1.25×25GB5786 10.9 Bolt
34 60149607 3 线束固定夹 Clamp, harness
35 12061846 3 弯板 bent plate
36 24000633 1 垫圈8GB97.1 达克锈 Washer
37 13515834 2 燃油箱放水管 drainage tube SY55C9I3R.1.3A.5-
38 A210307000028 1 螺母 Nut
39 11251714 1 接头 Adapter
40 60046622 1 燃油开关 Switch, fuel

41 变更或见其他配置 2 垫圈 Washer
42 11331654 1 接头 Adapter
