76 A820205002464 1 接头 Connector
77 变更或见其他配置 1 单向阀 Valve, check
78 A820205002466 1 接头 Connector
79 A210204000206 4 螺钉M12×35GB70.1 10.9级 Screw

80 21032354 2 胶管 Rubber hose
81 60212773 2 胶管 Rubber Hose
82 B230103004807 1 胶管 Hose, rubber
83 60153884 2 胶管 Hose, rubber
84 B230103000858 1 胶管 Hose Assembly
85 B230103006329 1 胶管 Hose, rubber
86 B230103000355 1 胶管 Hose Assembly
87 60022399 1 胶管 Hose
88 60153885 2 胶管 Hose
89 B230103004810 1 胶管 Rubber hose
90 60153882 1 胶管 Hose
91 B230103001183 1 胶管 Hose Assembly
92 变更或见其他配置 1 胶管 Hose
93 变更或见其他配置 1 胶管 Hose, rubber
94 B230103000353 1 胶管 Hose Assembly
95 B230103004130 1 胶管 Hose Assembly
96 21023911 1 胶管 Hose Assembly
97 B230103000583 1 胶管 Hose Assembly
98 变更或见其他配置 1 胶管 Hose

99 B230103003833 1 胶管 Hose

1 60038285 1 挡圈 Ring, retaining
2 60038852 1 密封圈 Ring, sealing
3 60038052 1 泵壳 Housing, pump
4 60038478 1 螺堵 Plug
5 60038127 1 轴承 Bearing, ball
6 60038818 1 O形圈 O-ring
7 60038103 1 控制阀 Valve, control
8 60038878 1 控制阀 Valve, control
9 60038561 2 内六角螺钉 Bolt
10 60038425 1 接头 Connector Ⅱ
11 60038372 2 过渡螺母 Nut
12 60037977 1 管 Pipe
13 60042321 1 SY65C主泵维修包 Repair kit,pump,main

1 60038591 1 驱动轴 Shaft, drive
2 60038627 1 旋转斜盘 Plate, swash
3 60037999 1 回转组件 Upper frame AS
4 60038366 1 固定板 Plate, fixing
5 60038587 1 球面衬套 Sleeve, spherical
6 60038352 1 反向活塞 Piston, reverse
7 60038214 1 弹簧 Spring
8 60038357 1 缸体 Block, cylinder
9 60038657 1 支撑盘 Disk, supporting
10 60038403 1 活塞导套 Bushing, guide, piston
11 60038218 1 弹簧 Spring
12 60038300 1 挡圈 Ring, retaining
13 60038005 1 控制盘 Board, control
14 60038331 1 调节垫片 Shim, adjusting
15 60038126 1 轴承 Bearing, ball
16 60038745 1 O形圈 O-ring
17 60038439 1 壳体 Housing
18 60038554 4 内六角螺钉 Screw
19 60038477 2 螺堵 Plug
20 60038534 1 密封垫 Gasket, seal

21 60038102 1 控制阀 Valve, control
22 60038562 4 内六角螺钉 Bolt
23 60038640 1 油缸销 Pin, cylinder
24 60038371 4 管接头 Connector
25 60038446 1 控制活塞 Piston, control
26 60038621 1 小缸体 Block, cylinder
27 60038631 3 压力销 Pin, pressure
28 60038560 1 内六角螺钉 Bolt
29 60037944 1 从动器 Driven unit
30 60038182 1 衬套 Sleeve
31 60038183 1 衬套 Sleeve
32 60038741 4 O形圈 O-ring
33 60038141 2 轴承瓦 Bushing, bearing
34 60038423 1 接头 Connector Ⅰ

1 60086730 1 进油联阀片组件 Plate GP, oil inlet valve
2 60086713 1 动臂联阀片组件 Plate GP, valve, boom
3 60086710 1 铲斗联阀片组件 Plate GP, valve, bucket
4 60086714 1 斗杆联阀片组件 Plate GP, valve, arm
5 60086733 2 行走联阀片组件 Plate GP, travel valve
6 60086726 1 辅助联阀片组件 Plate GP, valve, auxiliary
7 60086732 1 推土铲联阀片组件 Plate GP, dozer blade valve
8 60086728 1 回转联阀片组件 Plate GP, swing valve
9 60086785 1 后端盖 Glass, rear
10 60086799 4 螺柱 Stud
11 A210307000012 4 螺母 Nut
12 60211977 1 多路阀维修包 Multi-way valve repairing kit

1 60086781 1 阀片间密封组件 Seal GP, valve
2 60038741 2 O形圈 O-ring
3 A230101000499 1 O形圈 O-ring
4 60086729 1 进油阀片 Plate, oil inlet valve
5 60086691 1 调节组件 Adjusting GP
6 60083926 1 调速阀 Valve, speed adjusting
7 60038541 1 密封组件 Seal AS
8 23001937 1 O形圈 O-ring 15×2.0(GB3452.1)
9 60038033 1 止推环 Ring, thrust
10 60038731 1 O形圈 O-ring
11 60038151 1 过滤器 Filter
12 60038055 1 LS安全阀 Valve, relief
13 60038537 1 密封组件 Seal AS
14 23002753 1 O形圈 O-ring
15 60038032 1 止推环 Ring, thrust
16 60038733 1 O形圈 O-ring
17 60008387 2 锁盖 Cover, lock

1 60086781 1 阀片间密封组件 Seal GP, valve
2 60038741 2 O形圈 O-ring
3 A230101000499 1 O形圈 O-ring
4 60086727 1 工作阀片 Plate, valve
5 60086720 1 阀芯 Spool, valve
6 60086712 2 单向阀组件 Valve GP, check
7 60086776 2 堵头 Plug
8 60086757 2 弹簧 Spring
9 60086731 2 提升阀 Valve, lift
10 60038027 1 压力补偿组件 Compensator GP, pressure
11 60038390 1 活塞 Piston
12 60008387 2 锁盖 Cover, lock
13 60038057 2 安全阀 Valve, safety
14 60038540 2 密封组件 Seal AS
15 60038736 2 O形圈 O-ring
16 24001013 2 O形圈 O-ring
17 60086706 1 液压操作组件 Hydraulic operation GP
18 A210204000116 4 螺钉 Screw
19 60086692 2 盖 Cover
20 60086755 2 弹簧 Spring

21 60086766 2 弹簧座 Seat, spring
22 60008832 2 O形圈 O-ring
