1 60274597 1 胶管 rubber hose
2 61017817 1 胶管 Hose
3 13441702 1 支架 supportⅠ
4 A210204000167 21 螺钉M12×25GB70.1 10.9级 Screw
5 13545775 1 连接体 connection body
6 B230101000366 6 O形圈 O-ring
7 A210204000272 4 螺钉M12×120GB70.1 12.9级 Screw
8 60171840 1 单向阀 Check Valve
9 12349191 1 固定块 plate
10 12349192 1 固定块 plateSY365CAI2KS.1.2.4-3
11 12349193 1 橡胶衬套 Cushion
12 A210204000359 6 螺钉 Screw
13 14154202 1 回油钢管总成 Steel Pipe Assy
14 61013348 1 胶管 Hose assembly
15 14173688 1 支架 support Ⅱ
16 13545777 1 连接体 connection body
17 61013352 1 胶管 Hose assembly
18 B230103004203 1 胶管 Rubber Hose
19 B230103002647 1 胶管 Rubber Hose 1SN20-DKOL-
20 14154139 1 主阀回油钢管 Steel tube assembly

21 A210204000464 4 螺钉M12×90GB70.1 10.9级 Screw M12×90GB70.1 Grade 10.9
22 12349202 1 弯板 bent plate
23 21025050 1 U形螺栓 U type bolt
24 A210307000031 4 螺母M12GB6170 10级 Nut
25 12350498 1 钢管总成 Steel Pipe Assy
26 61013350 1 胶管 Hose assembly
27 61013349 1 胶管 Hose assembly
28 14210589 1 固定支架 Supporting shelf
29 60086356 1 线束固定夹 Clamp
30 A210111000012 1 螺栓 M10×20GB5783 10.9级 Bolt
31 60086355 1 线束固定夹 the fixity of line
32 14154335 1 回油钢管总成 Steel Pipe Assy
33 60349526 1 胶管 Rubber hose
34 12349200 1 固定卡 stator
35 12349201 1 橡胶护套 Cushion
36 A210204000203 1 螺钉M16×40GB70.1 10.9级 Screw
37 A210491000118 1 垫圈 High-strength steel washer
38 61017816 1 胶管 Hose
39 14154140 1 油箱连接体 right angle flange
40 A820205002280 4 接头 Connector

41 B230101000090 4 O形圈 O-ring
42 B210780000028 8 直角组合接头 Fitting, Elbow
43 A820205000945 1 G1-M30接头 Connector
44 B230101000050 3 O形圈 O-ring
45 60205581 1 单向阀 Valve, check
46 A210204000338 8 螺钉M12×40GB70.1 10.9级 Screw
47 A210204000206 10 螺钉M12×35GB70.1 10.9级 Screw
48 B210780000890 4 对开法兰 Split Flange
49 A210204000343 32 螺钉 Screw
50 B210780000741 16 对开法兰 Split Flange
51 A820205000837 1 接头 M24-M30joint
52 A230101000244 1 O形圈 O-ring
53 B210780000838 1 直角组合接头 Swivel Elbow Connector
54 12840728 1 G1-M36(L96)接头 JointSY365CAI2KS.1.2.4-20
55 13269673 1 G1-M36-L145接头 Joint SY50C1K3NU.1.2-11
56 A820205000942 2 接头 Fitting
57 B230101000356 2 O形圈 O-Ring-23.7
58 13307372 2 管夹 clamp
59 11206238 2 Φ26胶垫 Φ26 rubber cushion
60 A210307000055 4 螺母M8GB6170 10级 Nut

61 24000633 4 垫圈8GB97.1 达克锈 Washer
62 A210111000343 4 螺栓M8×20GB5783 10.9级 Bolt

1 60049355 4 胶管 Rubber Hose
2 12345776 1 支架 BracketSY365CAI2KS.1.2.3.1
3 14154067 1 动臂提升钢管总成 Steel tube assembly
4 14154123 1 动臂下降钢管总成 Steel tube assembly
5 14153987 1 动臂提升钢管总成 Steel tube assembly
6 14154109 1 动臂下降钢管总成 Steel tube assembly
7 61013340 1 胶管 Hose assembly
8 61013339 1 胶管 Hose assembly
9 61013341 2 胶管 Hose assembly
10 60043410 1 减速机总成 Reducer assembly
11 61013344 1 胶管 Hose assembly
12 61013345 1 胶管 Hose assembly
13 14154192 2 主阀进油钢管总成 Steel tube assembly
14 B230101000456 4 O形圈 O-ring
15 A210204000215 16 螺钉M10×35GB70.1 10.9级 Bolt
16 B230101000578 4 O形圈 O-ring
17 A210204000353 8 螺钉M14×50GB70.1 10.9级 Screw
18 A820301016459 1 定位销 Lock pin
19 A210204000454 48 螺钉M14×45GB70.1 10.9级 Screw
20 B210780000693 24 对开法兰 Flange, Split

21 A229900005717 3 U形螺栓 U-Bolt
22 A210491000121 10 垫圈 Washer
23 A210307000031 12 螺母M12GB6170 10级 Nut
24 A210204000354 32 螺钉 M10×30GB70.1 10.9级 Screw
25 B210780000696 4 对开法兰 Flange, split
26 B210780000244 12 对开法兰 Flange, Split
27 A210111000202 4 螺栓 Bolt
28 14173653 1 铲斗钢管支架焊合 Support welding
29 14173650 1 支架钢管 Bracket Steel Tube
30 21001328 7 垫圈 Washer
31 A210204000356 1 螺钉 M10×50GB70.1 10.9级 Bolt
32 A210204000198 1 螺钉M16×35GB70.1 10.9级 Bolt, socket head
33 A210491000118 1 垫圈 High-strength steel washer
34 A820205002352 1 G3/4-M36接头 Connector
35 B230101000356 1 O形圈 O-Ring-23.7
36 13186700 1 33T呼吸管总成 motor oil filler pipe
37 13186699 1 33T固定支撑板 plate
38 11160698 3 U型螺栓 U type bolt
39 A210307000036 8 螺母 Nut
40 60263201 1 通气帽 Cap, breather

41 A210204000343 8 螺钉 Screw
42 14153991 1 铲斗大腔钢管总成 Steel tube assembly
43 14153995 1 铲斗小腔钢管总成 Steel tube assembly
44 60217140 1 压力传感器 Sensor, pressure

1 60180837 1 回转马达 Rotary motor
2 60042755 1 减速机 Gearbox
3 60204228 1 回转机构维修包 Maintenance bag of slewing gear

1 60081480 1 座 Seat
2 60039294 1 油密封 Seal, oil
3 60039425 1 O形圈 O-RING
4 60039426 1 O形圈 O-ring
5 B229900003195 3 30T回转制动主动片 Driven piece, swing brake
6 B229900003194 4 30T回转制动从动片 Driven piece, swing brake
7 B220401000688 1 回转马达延时阀 Valve,brake,delay
8 60038566 3 内六角螺栓 Screw, socket head
9 60081466 1 驱动轴 Shaft drive

1 60081457 1 活塞组件 Piston GP
2 60039347 9 活塞 Piston
3 60081408 9 滑靴 Slipper
4 60039358 1 壳体总成 Assembly, housing
5 60038721 2 O形圈 O-ring
6 60039385 2 销 Pin
7 60039338 1 缸体 Cylinder block
8 60039322 1 弹簧座 Seat, spring
9 60039382 1 托架 Bracket
10 60039375 1 配油盘 Tray, oil distribution
11 60039336 1 阀座 Seat, valve
12 60039351 2 活塞 Piston
13 60081437 2 弹簧 Spring
14 60038547 1 铭牌 Nameplate
15 60038620 2 销子 Pin
16 60039367 4 内六角螺钉 Screw, socket head
17 60110639 2 回转马达溢流阀芯 Spool, relief valve, swing motor
18 60039401 2 油塞 Plug, oil
19 60039429 1 O形圈 O-RING
20 60039423 2 O形圈 O-RING

21 60039406 1 制动活塞 Piston, braking
22 60039405 16 制动弹簧 Spring, retarding
