1 A210110000456 Bolt 2
2 A210444000004 Washer 2
3 11686108 Lock Plate 4
4 60008208 Shock Absorber 4
5 12833149 Engine Front Outrigger 2
6 A210444000001 Washer 8
7 A210111000209 Bolt 8
8 13297295 Lock Nut 2
9 A210110000246 Bolt 2
10 A210444000003 Washer 2
11 11686109 Lock Plate 4
12 60008209 Damper 4
13 11749352 Engine Rear Support Leg 2
14 A210491000118 Washer 8
15 A210111000243 Bolt 8
16 13289490 Lock nut 2
17 61005649 Coupling 1
18 A210204000354 Screw 8

1 13300963 Waterproof Assembly 1
2 13294815 Exhaust Connection Pipe 1
3 A210491000121 Washer 11
4 A210111000204 Bolt 7
5 60250933 Exhaust Washer 2
6 60250934 Exhaust Gasket 8
7 60250935 Exhaust Nut 4
8 60250310 Muffler 1 2-254

9 13632605 Muffler Clamp 2
10 A210855000003 Hose Clamp 1
11 10250095 Plumbing, Water Drain 1
12 A210110000437 Bolt 4
13 12215066 Rubber Pad 1
14 13285648 Silencer Bracket 1
15 A210307000031 Nut 12
16 A210444000001 Washer 8
17 A210111000205 Bolt 4
18 11450892 Coupling Plate 2
19 60060550 Washer 4
20 A210111000208 Bolt 4

1 60310022 Tail Pipe 1
2 60310023 Fixed Clamp 1
3 60310024 Cylinder Body 1

1 13548761 Fuel Tank Assembly 1 2-264

2 A210110000201 Bolt 6
3 11450168 Spacer Sleeve 6
6 A210111000195 Bolt 16
7 A210491000120 Washer 52
10 11133736 Boot 4
11 60086357 Harness Fixing Clamp 9
24 A210111000079 Bolt 4
25 60238783 Washer 6
27 13288172 Circulation Pump Oil Outlet Pipe 1
36 A230101000501 O-ring 4
37 13290936 Bracket Assembly 1
38 A210111000203 Bolt 4
39 A210491000121 Washer 17
47 10442581 Filter JointⅠ 3
48 A210199004057 Articulated Bolt 3
49 A210434000009 Washer 6
58 A210111000026 Bolt 3
59 60205949 Fuel Filter 1 2-270

60 14159300 Circulation Pump Oil Inlet Pipe 1
61 13288054 Fuel Tank Coarse Filter Inlet Pipe 1
62 60248975 Circulation Pump 1
84 A210855000008 Throat Clamp 4

4 60134354 Throat Clamp 11
5 13807104 Coarse Filter Inlet Oil Pipe Ii 1
8 60149605 Harness Fixing Clamp 10
9 13288197 Fuel Pipe 1
10 11133736 Boot 4
11 60086357 Harness Fixing Clamp 9
12 13288242 Oil Drain Pipe 1
13 150405010095B Ball Valve 2
14 10578844 U-Bolt 4
15 24000633 Washer 8
16 A210307000055 Nut 8
25 60238783 Washer 6
26 A210111000082 Bolt 2
39 A210491000121 Washer 17
40 13807108 Fuel Pipe 1
41 A210111000202 Bolt 8
42 13807109 Electromagnetic Pump Inlet Pipe 1
45 13807110 Electromagnetic Pump Outlet Pipe 1
52 60018583 Fuel Pump Assembly 1 2-268

53 13807113 Bracket Assembly 1
56 60208141 Harness Fixing Clamp 1
57 13807156 Three-way Connector 2
63 60202896 Clamp 14
64 13807107 Coarse Filter Inlet Oil Pipe Iii 1

7 A210491000120 Washer 52
8 60149605 Harness Fixing Clamp 10
17 10949800 Drainage Tube 3
18 A229900001345 Clamp 3
19 13288038 Coarse Filter Connecting Pipe I 1
20 60249071 Oil-water Separator 1 2-266

21 A210111000101 Bolt 5
22 B229900004534 Spacer 20
23 60250938 Parallel Connecting Pipe 4
28 60250939 Two-hole Hinge Bolt 4
29 A210111000197 Bolt 7
30 B230101000356 O-ring 2
31 13291588 Fitting, Connector 2
32 13287706 Oil Inlet Pipe 1
33 A210111000024 Bolt 4
34 60060546 Washer 4
35 13291554 Filter Bracket I 1
36 A230101000501 O-ring 4
39 A210491000121 Washer 17
43 A240600000260 Water-in-oil Sensor 1
44 13287950 Fine Filter Outlet Oil Pipe 1
46 13291518 Diesel Filter Fixing Bracket Ii 1
47 10442581 Filter JointⅠ 3
48 A210199004057 Articulated Bolt 3
49 A210434000009 Washer 6
50 13291147 Joint 1
51 13288031 Coarse Filter Outlet Oil Pipe 1
54 A210111000295 Bolt 4
55 21005186 Bolt 8
63 60202896 Clamp 14
