4 60134354 Throat Clamp 11
6 A210111000195 Bolt 16
7 A210491000120 Washer 52
8 60149605 Harness Fixing Clamp 10
11 60086357 Harness Fixing Clamp 9
23 60250938 Parallel Connecting Pipe 4
29 A210111000197 Bolt 7
39 A210491000121 Washer 17
41 A210111000202 Bolt 8
63 60202896 Clamp 14
65 13285390 Rubber Sleeve T5-T10 1
66 13284401 Oil Return Pipe 1
67 JGK005465335 Engine Oil Hose 1
68 60027557 Engine Oil Hose 1
69 B230101000050 O-ring 4
70 13285543 Boot 1
71 14135986 Mounting Seat 1
72 A820205000945 G1-M30 Connector 4
73 A210110000447 Bolt 2
74 13630332 bracket 1
75 A820606020470 Φ34 Rubber Cushion 2
76 13285399 Protective Sleeve 2
77 13285207 Oil Return Pipe 2 1
78 12020025 Pipe Clamp 2
79 13285524 Rubber Pad 2
80 13807111 Fuel Pipe 1
81 B210780000028 Elbow Combination Joint 2
82 21008534 Screw 3
83 A210204000477 Screw 2

1 A210111000078 Bolt 4
2 24000632 Washer 4
3 60029642 Liquid Level Sensor 1
4 B230101000457 O-ring 1
5 60117826 Fuel Tank Filter Screen 1
6 10210082 Screw Plug 1
7 13548775 Bottom Cover Plate 1
8 60312034 Door Lock 1
9 A210111000101 Bolt 8
10 24000639 Washer 8
11 A210609000307 O-ring 1

1 60310025 Handle 1
2 60310026 Cylinder Body 1
3 60310027 Seat 2
4 60310028 Water Cup 1
5 60310029 Water Draining Device 1
6 60249072 Oil-water Separator Filter Element 1

1 60311898 Washer 2
2 60311899 Pillar Ring 2
3 60311900 Washer 1
4 60333882 Filter Element 1
5 60311901 Electronic Pump Service Kit 1

1 60205741 Fuel Filter Seat 1
2 60206017 Fuel Filter Element 1
3 60205740 water cup 1

1 A210111000204 Bolt 6
2 A210491000121 Washer 18
3 14542897 Angle Plate 1
4 13422096 Adjusting Shim 1
5 160601000020A Air Cleaner&Air Prefilter 1 2-276

6 14542896 Bracket 1
7 21005240 Bolt 3
8 60060550 Washer 3
9 14520525 Oil Bath Bracket Assembly 1
10 60060548 Washer 8
11 A210111000209 Bolt 4
12 A210444000001 Washer 4
13 13421240 Oil bath support 1
14 A210111000054 Bolt 4
15 14363145 Thickening Washer 4
16 13282184 Pipe 1
17 A210111000101 Bolt 10
18 A210111000202 Bolt 8
19 13282172 Fixed Mount of Air Cleaner 1
20 60065525 Atmospheric Pressure And Temperature Sensor 1
21 A210204000115 Screw 3
22 24000630 Washer 3
24 A210110000009 Bolt 4
41 60241870 Air Filter 1 2-278

42 60148482 Pressure Sensor 1
43 13547902 Air Intake Rubber Hose 1
44 60275328 T-style Spring Clamp 1
45 13282175 Air Intake Steel Pipe Combination 1
46 60247180 T-style spring clamp 5
47 13282165 Air Filter Exhaust Pipe 1
48 14552134 Air Intake Rubber Tube 1
50 10131920 Air Filter Clamp 2
51 A210111000111 Bolt 2
54 60250930 Air Intake Temperature Sensor 1
55 13282164 Air Intake Rubber Hose 1
56 A210855000071 T-style anchor ear 2

10 60060548 Washer 8
17 A210111000101 Bolt 10
23 A210111000024 Bolt 12
25 13282158 Lock Plate 1
26 13282170 Rubber Sleeve 1
27 13282168 Intercooler Air Intake Steel Pipe 1
28 60205838 T-style spring clamp 18
29 13282160 Connecting Rubber Hose I 1
30 13282163 Connecting Rubber Hose 1
31 13282196 Fixing Plate Assembly 1
32 13282162 Inter-cooler Outlet Pipe Ⅱ 1
33 11453375 Soft pad 2
34 12832053 Lock Plate 2
35 13282161 Connecting Rubber Hose II 2
36 13282169 Intercooler Air Outlet Pipe I 1
37 12832004 Fixing Plate Assembly 1
38 13394552 Cover Plate 1
39 A210111000012 Bolt 5
40 A210491000120 Washer 19
49 13282186 Rigid Bracket 1
52 13282167 Connecting Rubber Hose 1
53 60227325 T-style spring clamp 1
